Gradall Forklift Parts - The Gradall excavator was the creation of two brothers Koop and ray Ferwerda. The excavator was founded In the 1940's throughout World War II, when there was a scarcity of labourers. Partners in a Cleveland, Ohio construction business known as Ferwerda-Werba-Ferwerda, the brothers faced a huge dilemma when so many men left the workforce and signed up in the military, depleting existing workers for the delicate finishing work and grading on highway projects. The Ferwerda brothers chose to make a machine which will save their business by making the slope grading job less manual, easier and more efficient.
Their first design model was a device with two beams set on a rotating platform which was affixed on top of a used truck. A telescopic cylinder moved the beams back and forth that allowed the fixed blade at the end of the beams to pull or push dirt. Before long enhancing the first design, the brothers made a triangular boom so as to add more strength. As well, they added a tilt cylinder which let the boom rotate 45 degrees in both directions. A cylinder was positioned at the rear of the boom, powering a long push rod to allow the machinery to be equipped with either a bucket or a blade attachment.
Gradall launched in 1992, with the introduction of the new XL Series hydraulics, the most ground-breaking adjustment in their machinery ever since their creation. This new system of top-of-the-line hydraulics enabled the Gradall excavator to provide high productivity and comparable power to the more traditional excavators. The XL Series put an end to the initial Gradall equipment power drawn from low pressure hydraulics and gear pumps. These conventional systems efficiently handled grading and finishing work but had a difficult time competing for high productivity work.
The new XL Series Gradall excavators proved a significant increase in their lifting and digging ability. These versions were made together with a piston pump, high-pressure hydraulics system which showed huge improvements in boom and bucket breakout forces. The XL Series hydraulics system was likewise developed together with a load-sensing capability. Conventional excavators use an operator to select a working-mode; where the Gradall system could automatically adjust the hydraulic power intended for the work at hand. This makes the operator's whole job easier and even saves fuel simultaneously.
Once their XL Series hydraulics came onto the market, Gradall was essentially thrust into the highly competitive market of equipment meant to deal with pavement removal, excavation, demolition as well as several industrial tasks. Marketability was further enhanced with their telescoping boom due to its exclusive ability to work in low overhead areas and to better position attachments.
